Overall Length

mm

306-475

535-545

600

765

924-944

983-1050

1006-1773

Overall Height

mm

230-265

307

310

388

492

574

558-610

Overall Width

mm

175-242

258-263

270-280

353-436

449-483

543-568

606-663

Pin to Pin Center Distance

mm

86-200

230-270

290-360

380-420

460-480

473-540

550-620

Forearm Open Width

mm

86-185

155-170

180-200

232-315

306-340

375-411

416-469

Retractable Distance of Oil Cylinder

mm

90-140

208-318

340-450

340-486

256-390

413-590

520-590

Top to Bottom Pin Distance

mm

159-165

150

195

220

275

300

360

Pin Diameter

Φ

25-40

45-50

50-55

50-70

70-80

80-90

90-120

Weight

Kg

30

50-60

80

120-130

280-290

420-430

450-580

Working Pressure

Kgf/cm²

40-380

40-380

40-380

40-380

40-380

40-380

40-380

Required Oil Flow

L

10-20

10-20

10-20

10-20

10-20

10-20

10-20

Suitbale Excavator

Ton

0.8-3.5

3-7

5-8

9-19

17-23

23-30

33-45
